Micronet SP1658C Switch Managed Layer 2 ขนาด 24 Port 10/100Mbps, 2 Port Gigabit พร้อม 2 mini-GBIC

Product Specification

Overview

MicroNet SP1658C อุปกรณ์ Layer 2 Managed Switch ขนาด 24 Port ความเร็ว 10/100Mbps และ 2 Port ความเร็ว 10/100/1000Mbps พร้อม 2 Port mini-GBIC

Standard

IEEE802.3, 10Base-T
IEEE802.3u, 100Base-TX
IEEE802.3u, 100Base-FX
IEEE802.3ab 1000Base-T

Interface

24 10/100M, RJ-45 ports
2 10/100/1000M, RJ-45 ports
2 mini-GBIC Slot

Hardware

384K Buffer Memory
8K Mac Address Table

Layer 2 Feature

Auto Negotiation
Auto MDI/MDI-X
IEEE802.3x, Flow Control
256 802.1Q VLANs
Tag-based/Port-based VLAN
Broadcast/Multicast/Unicast Storm Control
GVRP
Management VLAN
IEEE802.3ad LACP (8 Port/14 Group)

QoS

IEEE802.1p, VLAN Information Based CoS
Priority Queue(Strict Priority)
IP ToS/IP Precedence Based CoS
Port Based CoS/DSCP Based CoS
QoS Remarking

Security

IEEE802.1x 24 Dynamic MAC Address Based Port Security
254 ACL(Access Control List) Entries
Mac Address Filtering
IEEE802.1d/w/s Spanning Tree protocol
RSTP Root Guard
Management IP List
SSH/SSL
Dynamic ARP Inspection and Port Self-Loop Detection

Management

Console
Telnet
Web-based Management
BOOTP/DHCP Client/DHCP Relay
Cable Diagnostics
RADIUS
Firmware Upgradable

SNMP & MIBs

SNMPv1
SNMPv2c
SNMPv3
RMON

Environment

Temperature: Operating: 0~40oC, Storage: -40~70oC
Humidity: Operating: 20~85% (Non-Condensing)

Power

100-240V, 50-60Hz

Dimension

430 x 178 x 44 mm
